Name:203A Egg washer
Product Code:203A
Capacity:20,000 eggs/hour
Function:Accumulator, candling, sanitizer sprayer, washing, drying
Details
Overview
The ZENYER 203A egg washer is a high-efficiency industrial-grade solution engineered for large-scale egg processing operations. this model integrates two single-row systems to deliver a remarkable capacity of 20,000 eggs per hour. It combines egg accumulation, candling, orienting, sanitizing, washing, and drying into one seamless workflow, with optional accessories available for full automation and traceability. Ideal for demanding production environments, it ensures thorough cleaning, effective drying, and compatibility with grading systems for end-to-line efficiency.
Features:
Robust Stainless Steel Construction
Manufactured from high-quality stainless steel to ensure long-term durability, corrosion resistance, and compliance with hygiene standards.
High-Capacity Dual-Row Design
Combines two single-row egg washers for a total throughput of 20,000 eggs per hour, meeting high-volume cleaning and drying demands.
All-in-One Automated Process
Integrates accumulation, candling, orienting, sanitizing, washing, and drying in one continuous system. Optional upgrades include an auto egg loader, egg printer, and manual collection conveyor.
Efficient Loading & Candling
Eggs are manually loaded in batches of 30 using the 602 vacuum egg lifter. A 6-row candling section with LED lighting, candling cover, and mirror allows visual inspection and removal of defective eggs.
Orientation
An orientator smoothly directs six rows of eggs into two single rows, feeding them into the dual washing units.
Automatic Sanitizing
A proportional doser automatically sprays customer-supplied sanitizer or detergent onto eggs to ensure food safety compliance.
Thorough Brush Washing
Eggs are cleaned with rotating brushes and warm water for effective dirt removal (water heater available as an optional accessory).
Advanced Drying Performance
Brushes remove excess water, and a dedicated drying system achieves 95%–99% dryness depending on ambient humidity.
Seamless Grading Line Integration
Designed to connect with the ZENYER 107 egg grader to form the ZENYER 303A egg washing and grading line, maintaining a capacity of 20,000 eggs per hour.
| Commodity | Egg washer |
| Product code | 203A |
| Model | ZYX-JS2-3-(P) |
| Capacity | 20,000 eggs/hour |
| Material | Stainless steel |
| Power | 21.46KW |
| Voltage | 380V, 50HZ, 3-phase |
| Dimension (L*W*H) | 12.16*5.56*2.0 M |
| Net weight | 1830KG |
| Gross weight | 2610KG |
| Function |
Accumulator & candling,sanitizer sprayer, brush washing & drying, optional printer , vacuum egg lifter and manual collection conveyor |




.jpg)





Option:
