Name：300A Egg washing grading line

Product Code：300A

Capacity：3,000 eggs/hour

Function：Candling,sanitizer sprayer, washing, drying,grading

Details

ZENYER 300A Egg Washing & Grading Line – Features & Benefits

• New 2024 Model – Stronger & More Hygienic

Built from stainless steel for maximum durability, corrosion resistance, and hygiene, making it ideal for continuous farm or packing station use.

• Complete Egg Washing & Grading Solution

ZENYER 300A egg washing grading line is comprised of ZENYER 200A egg washer, 604A accumulator  and 101B egg grader.

• Integrated Processing

Including single roller conveying, candling, sanitizer sprayer, washing, drying, accumulator, grading & candling and optional egg printer with a capacity of 3,000 eggs/hour.

• Efficient & Flexible Operation

The standard single-roll  er conveyor allows for straightforward loading. For maximum efficiency and labor savings , pair with the the 604AS accumulator  and 602 vacuum egg lifter to semi-automatic loading.

• Flexible Installation Layout

Commodity	Egg washing grading line
Product code	300A
Model	ZYL-J1-J2
Capacity	3,000 eggs/hour
Material	Stainless steel
Power *	6.02KW
Voltage	220V, 50HZ, Single phase 380V, 50HZ, 3-phase
Dimension (L*W*H)	7.13*1.57*1.8 M
Net weight *	580KG
Gross weight *	850KG
Function	Candling,sanitizer sprayer,washing, drying , accumulator, grading

* Power, net weight and gross weight are calculated according to the floor plan below.

The ZENYER 300A Egg washing grading line

Straight line floor plan

Left turn floor plan

ZENYER 200A egg washer

ZENYER 604A accumulator

2-row divider which can match with the 101B egg grader

The 604A matches with the egg washer with 90-degree turn

ZENYER 101B egg grader
Control panel

 ZENYER 602 Vacuum egg lifter system

The 604AS accumulator & 602 vacuum egg lifter for egg loading (optional)

604AS+602+300A line

Price for ZENYER 300A Egg washing grading line standard configuration: Only CNY153,000.00
Consist of :

• The 200A Egg washer  (Washing & Drying included)

• The 604A  Accumulator

• The 101B egg grader (Grading & candling included)

Option:

• The 602 Vacuum egg lifter : CNY8,700.00

• The 604AS accumulator : CNY12,050.00

• The 401H egg printer : CNY26,000.00

(Pre-order)

300A Egg washing grading line Brochure
